Fluidlink Autopacks - Micro Hydraulic Power Packs

Much smaller than mini hydraulic power packs, the Fluidlink autopacks – micro hydraulic power packs is ideal for applications needing a particularly compact hydraulic power unit…

Fluidlink Autopacks are available as both unidirectional and reversible and can be fitted with a range of 3″ AC & DC motors.

Reversible units have an integral Pilot Operated Check (POC) to hold a cylinder in place when the unit is switched off; the reversible action eliminates the need for a directional valve. Unidirectional units can be fitted with a lowering valve for single acting “lift, hold, dump” circuits.

The Autopack is commonly used on bath lifts, coffin lifts and other applications which require a small hydraulic unit. With a solid centre body the Autopack is available with 12/24V DC and 230V AC, motors from 150W-800W and can produce pressures of up to 180bar with flows of up to 3 litres/minute.

Tanks are made from steel and plastic in several sizes: 0.2l, 0.5l, 0.75l and 1.0l.

Hydraulics CatalogueOur catalogue shows a selection of the standard, micro and mini hydraulic power packs that we hold within our range – but don’t worry if you’re not sure on what sort of hydraulic power pack you are looking for or if you are looking for a bespoke unit or system; our experienced team can determine what is best suited to your application.

Fluidlink Autopacks - Micro Hydraulic Power Packs

Call us now on: +44 (0)845 644 3640 or enquire online and "let us take the pressure!"
